Universal 2-Stage & 3-Stage
Water Filter Housing Systems
Universal 2-Stage & 3-Stage
Modular Water Filtration, Engineered for Excellence
Our 2-stage and 3-stage universal filter housing systems are designed for maximum flexibility and reliable performance in a wide range of water treatment applications. Each stage accepts any standard 10” or 20” filter media, from sediment and carbon to deionization and softening resins—making them ideal for both home and commercial use.
MODEL NUMBER: Universal 2-Stage & 3-Stage
Features & Benefits
- Premium Build & Leak-Proof Design
- Virgin-Grade Polypropylene Housings: Constructed from first-use, non-recycled materials for superior strength, pressure resistance, and chemical compatibility
- Patented Leak-Proof Technology: Features exclusive O-ring designs and reinforced thread patterns, ensuring a tight, reliable seal every time
- Heavy-Duty Steel Wall-Mount Brackets (2-Stage & 3-Stage): Durable, powder-coated brackets for stable, wall-mounted installation
- Precision Leak-Proof Adaptors: Specially engineered adaptors prevent leaks and ensure consistent internal water flow
- Color Options: Available in Blue, Black, and White combinations
Detailed Description
Universal 2-Stage & 3-Stage are suitable for
- Home
- Commercial Use
Specifications
Product Series Name: UHF-2, UHF-3
Min. Operating Temperature: 4 °C / 40 °F
Max. Operating Temperature: 40 °C / 104 °F
Max Operating Pressure: 8.6 bar / 125 psi
Connections:
10” Standard: 3/4”
10” & 20” Jumbo: 1”
| Model Number | Connection | Color Cap | Color Sump | Size |
|---|---|---|---|---|
| Housing Kits with White Painted Steel Floor Stand – 2-Stage | ||||
| DMF-HP08V-8N-KB | 1” FNPT | Black | Blue | 20” Jumbo |
| DMF-HP08V-8B-KB | 1” BSP (F) | Black | Blue | 20” Jumbo |
| Housing Kits with White Painted Steel Floor Stand – 3-Stage | ||||
| TMF-HO6Y-6N-KB | 3/4” FNPT | White | White | 10” Standard |
| TMF-HO6Y-6B-KB | 3/4” BSP (F) | White | White | 10” Standard |
| TMF-HP07V-8N-KB | 1” FNPT | Black | Blue | 20” Jumbo |
| TMF-HP07V-8B-KB | 1” BSP (F) | Black | Blue | 20” Jumbo |
| TMF-HP08V-8N-KB | 1” FNPT | Black | Blue | 20” Jumbo |
| TMF-HP08V-8B-KB | 1” BSP (F) | Black | Blue | 20” Jumbo |
| Housing Kits with White Painted Steel Wall Mounting Bracket – 2-Stage | ||||
| DMW-HP07V-8N-KB | 1” FNPT | Black | Blue | 10” Jumbo |
| DMW-HP07V-8B-KB | 1” BSP (F) | Black | Blue | 10” Jumbo |
| DMW-HP08V-8N-KB | 1” FNPT | Black | Blue | 20” Jumbo |
| DMW-HP08V-8B-KB | 1” BSP (F) | Black | Blue | 20” Jumbo |
| Housing Kits with White Painted Steel Wall Mounting Bracket – 3-Stage | ||||
| TMW-HO6-6N-WW | 3/4” FNPT | White | White | 10” Standard |
| TMW-HO6-6B-WW | 3/4” BSP (F) | White | White | 10” Standard |
| TMW-HP07V-8N-KB | 1” FNPT | Black | Blue | 20” Jumbo |
| TMW-HP07V-8B-KB | 1” BSP (F) | Black | Blue | 20” Jumbo |
| TMW-HP08V-8N-KB | 1” FNPT | Black | Blue | 20” Jumbo |
| TMW-HP08V-8B-KB | 1” BSP (F) | Black | Blue | 20” Jumbo |
